# Growatt
Supported devices: 40KTL3-X, 60KTL3 LV, ShineMaster, and the MIC, MIN, MOD, MID, MAC and MAX grid-tied series
Our EMS supports integration with PV inverters and data loggers from Growatt. Growatt is a global manufacturer of solar inverters for residential, commercial, and industrial installations.
The integration enables centralized monitoring and control of Growatt production data through our EMS platform.
### Supported devices
We support the following Growatt devices:
* **40KTL3-X**: three-phase string inverter
* **60KTL3 LV**: three-phase low-voltage string inverter
* **ShineMaster**: data logger for aggregating and exposing inverter data
Beyond these, the grid-tied (non-storage) series below are supported through the generic Growatt integration, which reads the inverter and scales curtailment to its own nameplate power. They are grouped per family as Growatt lists them in its VPP protocol documentation, so pick the family your model belongs to:
| Series | Power range | Type |
| -------------------- | ------------- | -------------------------------------------- |
| **MIC TL-X** | 0.6 to 3.3 kW | single-phase string inverter |
| **MIN TL-X / KTL-X** | 2.5 to 10 kW | single-phase and three-phase string inverter |
| **MOD KTL3-X** | 3 to 33 kW | three-phase string inverter |
| **MID KTL3-X** | 11 to 50 kW | three-phase string inverter |
| **MAC KTL3-X** | 15 to 70 kW | three-phase string inverter |
| **MAX KTL3** | 50 to 350 kW | three-phase commercial inverter |
{% hint style="warning" %}
These six series are currently offered as **beta**. They are functional and can be added to a project, but they have not been through the same field validation as the 40KTL3-X, the 60KTL3 LV and the ShineMaster. Let Voltmasters know when you commission one, so we can follow it up.
{% endhint %}
### EMS functionality
With the current integration, our EMS enables:
* Monitoring of PV production data
* Active power curtailment where supported
* Integration of PV production into broader energy management strategies
### Add a Growatt inverter to the EMS
The connection method depends on how the inverter communicates:
**Modbus TCP (ShineMaster present)**\
If the inverter is connected via Modbus TCP, a ShineMaster data logger is present in the installation. In this case, add the device to the EMS using the **ShineMaster adapter** option in the device wizard.
**RS485**\
If the inverter communicates via RS485, you will need to use an **RS485-to-TCP converter** (such as the [EP E300](/getting-started/adding-and-verifying-devices/rs485-to-modbus-tcp-adapters/ep-e300.md)) before adding the device. The converter makes the inverter accessible over the network so that the EMS can communicate with it.
---
