# Sunny Boy / Sunny Tripower
Our EMS connects directly to SMA Sunny Boy and Sunny Tripower inverters over Modbus TCP for production monitoring and active-power curtailment. Most models integrate through the generic SunSpec adapter; a few families have a dedicated SMA-native adapter.
### Supported devices
* **Sunny Tripower 3.0 / 4.0 / 5.0 / 6.0 / 8.0 / 10.0** (STP3.0-STP10.0)
* **Sunny Tripower TL-20 series** (STP 5000TL-20, 6000TL-20, 7000TL-20, 8000TL-20, 9000TL-20, 10000TL-20, 11000TL-20, 12000TL-20)
* **Sunny Tripower TL-30 series** (STP 15000TL-30, 20000TL-30, 25000TL-30) and the TL-10 siblings STP 10000TL-10 and 17000TL-10
* **Sunny Tripower CORE1** (STP 50-40 / STP 50-41)
* **Sunny Tripower CORE2** (STP 110-60)
* **Sunny Tripower X** (STP 12-50 / 15-50 / 20-50 / 25-50)
* **Sunny Boy** and other SunSpec-capable SMA inverters
{% hint style="info" %}
Any SMA inverter that exposes the standardised **SunSpec Modbus** profile can be integrated through the generic **SunSpec** adapter, even if it is not listed by name above. See [SunSpec (Generic)](/device-integrations/pv-inverters/sunspec.md). To read several inverters through a single connection, use the [SMA Data Manager](/device-integrations/pv-inverters/sma/data-manager.md).
{% endhint %}
### EMS functionality
* Monitoring of PV production
* Active-power curtailment where the inverter exposes it (negative-price capping, fixed injection limit, zero injection)
* Integration of PV production into broader energy-management strategies (batteries, EV chargers, site consumption)
### Enable Modbus TCP
{% stepper %}
{% step %}
### Open the inverter interface
* **Connect** your laptop to the same network as the inverter.
* **Open** a browser and enter the inverter’s IP address.
* **Log in** with **Installer** credentials.
{% endstep %}
{% step %}
{% endstep %}
{% step %}
### Open device parameters
* Go to **Device Parameters > Edit Parameters**.
{% endstep %}
{% step %}
{% endstep %}
{% step %}
{% endstep %}
{% step %}
### Enable the TCP server
* Expand **External Communication → Modbus → TCP Server**.
* Set **Enabled = Yes** and **Port = 502**.
{% endstep %}
{% step %}
{% endstep %}
{% step %}
### Save the settings
* Click **Save All**.
{% endstep %}
{% endstepper %}
### Which adapter is used
Most SMA inverters integrate through the generic **SunSpec** adapter (`sunspec.generic`), which communicates over the standardised SunSpec Modbus register layout and covers production monitoring and control where the inverter exposes it. This is the default and the recommended starting point, see [SunSpec (Generic)](/device-integrations/pv-inverters/sunspec.md).
A few families need or offer a dedicated adapter that talks to SMA's **native** Modbus register map instead (exposing SMA-specific values such as per-phase active power and DC bus voltage/current, plus SMA's own active- and reactive-power control registers):
* **Sunny Tripower TL-20 series (legacy).** The TL-20 models predate SMA's SunSpec support and are integrated through the dedicated **"SMA Sunny Tripower TL-20"** adapter. Selecting a TL-20 model uses this adapter automatically.
* **Sunny Tripower CORE2 (STP 110-60).** The CORE2 does not work with the generic SunSpec adapter and uses the dedicated **"SMA Sunny Tripower CORE2"** adapter. Selecting the CORE2 model uses this adapter automatically.
* **Sunny Tripower TL-30 series.** The TL-30 models (STP 15000TL-30, 20000TL-30, 25000TL-30) default to SunSpec, but a dedicated **"SMA Sunny Tripower TL-30"** adapter is available as an **opt-in override**. It is not selected automatically: choose it per device when adding the device (or change the adapter afterwards). Left untouched, these models keep using SunSpec.
* **Inverters without SunSpec support.** Older Sunny Tripower units whose firmware does not expose SunSpec fall back to the dedicated **"SMA Modbus profile"** adapter.
{% hint style="warning" %}
Active-power curtailment (with any adapter) requires the inverter's Modbus **write access** and grid-management mode to be enabled in the SMA Installer settings, and the correct Modbus **Unit ID** to be configured. Without this, the EMS can read data but cannot send setpoints.
{% endhint %}
---
